Name: 4m 0.9mm PI Hydraulic Sheet Metal Bending Machine
Brand: Cangzhou Famous International Trading Co., Ltd
SKU: خمش پرس هیدرولیک
Price: 28,000.00 USD
Availability: InStock

خانه > محصولات > دستگاه رول فرمینگ سقف >

4m 0.9mm PI Hydraulic Sheet Metal Bending Machine

4m hydraulic sheet metal bending machine,0.9mm hydraulic sheet metal bending machine,PI hydraulic sheet metal bending machine

0.9mm hydraulic sheet metal bending machine

PI hydraulic sheet metal bending machine

محل منبع:

سرزمین اصلی چین

نام تجاری:

CANGZHOU WILLING

گواهی:

ISO CE

شماره مدل:

خمش پرس هیدرولیک

با ما تماس بگیرید

درخواست قیمت

جزئیات محصول

نام محصول:

دستگاه رول شکل دهی سقف خمشی ورق فولادی پرس هیدرولیک 4 متری

مواد خام:

PI، PPGI، PL، PPGL

سیستم کنترل:

PLC

ضخامت:

0.2-0.9 میلی متر

نوع کاشی:

خم

وضعیت:

جدید

رنگ:

طبق درخواست مشتری

قدرت موتور:

3 کیلو وات

برجسته کردن:

4m hydraulic sheet metal bending machine,0.9mm hydraulic sheet metal bending machine,PI hydraulic sheet metal bending machine

0.9mm hydraulic sheet metal bending machine

PI hydraulic sheet metal bending machine

شرایط پرداخت و ارسال

مقدار حداقل تعداد سفارش

1 مجموعه

قیمت

negotiable

جزئیات بسته بندی

20 دقیقه FLC

زمان تحویل

30 روز کاری

شرایط پرداخت

L/C ، T/T ، D/A ، D/P

قابلیت ارائه

40 مجموعه در هر ماه

محصولات مرتبط

ویدئو

Standard Corrugated Galvanized Sheets Machine Standard Corrugated Galvanized Sheets Line

بهترین قیمت رو بدست بیار

ویدئو

Corrugated Sheet Machine Corrugated Roofing Tile Roll Forming Machine

بهترین قیمت رو بدست بیار

ویدئو

Metal Roof Tile Trapezoidal Roll Forming Machine 5.5kw

بهترین قیمت رو بدست بیار

ویدئو

High Material Quality C89 Light Gauge Steel Framing Building Roll Forming Machine

بهترین قیمت رو بدست بیار

با ما تماس بگیرید

86-317-2016816

هم اکنون تماس بگیرید

توضیح محصول

4m Hydraulic Press Steel Sheet Bending Roof Roll Forming Machine

The bending machine is a machine that can bend thin sheet. Its structure mainly includes a bracket, a working table and a clamping plate. The working table is placed on the bracket. The working table is composed of a base and a pressing plate. The base is connected with a hinge and a clamping plate. Connected, the base is composed of a seat shell, a coil and a cover plate, the coil is placed in the recess of the seat shell, and the top of the recess is covered with a cover plate. When in use, the wire is energized to the coil, and the gravitational force is generated on the pressing plate after being energized, so as to realize the clamping of the thin plate between the pressing plate and the base. Due to the electromagnetic clamping, the pressing plate can be made into a variety of workpiece requirements, and the workpiece with side walls can be processed, and the operation is also very simple.

Specification

No.	Item	Description
1	Coil	Galvalume, Galvanized, PPGI, Aluminum
2	Raw Material Thickness	0.3-0.9mm
3	Working Speed	36times /min
4	Shear Angle	12
5	Dimension (LWH)	6000 mm1200 mm2000 mm
6	Machine Weight	700 KG
7	Electrical Control System	Manual
8	Drive Motor Power	3KW
9	Tile type	bending
10	Power Supply	380V, 60HZ, 3 PHASES(can be customized)
11	Cutting Accuracy	±2 mm
12	Driving Mode	Single Chain 1 inch
13	Material of Shaft	70 mm 45#steel forged
14	Material of Roller	45# Steel Finish Machining, Plated Hard

Application

The shearing machine is mainly used for cutting sheet metal and is an important sheet metal processing machine tool. It is not only used in the machinery manufacturing industry, but also an indispensable equipment for sheet metal matching, with a particularly wide range of applications.

Advantage

Our company is a manufacturer of cold-formed forming equipment and automatic complete production lines. For many years, it has been engaged in the production of roof panels and wall profiled panels for steel structures. The products have been manufactured from ordinary roof panels and wall panel forming machines to now. Several series of profiled board production lines can fully meet the needs of steel structure construction. The products include hidden roof panel forming machine, sandwich composite panel production line series, roof panel, wall panel forming machine series, and double-layer color steel tile forming machine Series, glazed tile forming machine series, angle-chi pressure tile machine series, C/Z steel equipment series, floor deck forming machine series, advertising pull trigger series, rolling door forming machine series, arch equipment series, carriage board machine series, water stop Steel plate forming machine series, high-speed guardrail forming machine series, bending machine, shearing machine series, other auxiliary equipment series and other products, the product quality is certified, welcome to your inquires.
