1.2mm Profile Pressing Dot Floor Deck Roll Forming Machine

1.2mm floor deck roll forming machine,profile floor deck roll forming machine,pressing dot floor deck forming machine

profile floor deck roll forming machine

pressing dot floor deck forming machine

محل منبع:

سرزمین اصلی چین

نام تجاری:

FMS

گواهی:

ISO CE

با ما تماس بگیرید

درخواست قیمت

جزئیات محصول

نام محصول:

دستگاه شکل دهی رول پروفیل B Deck محبوب در بازار ایالات متحده با نقطه فشار

تایپ کنید:

عرشه کف گالوانیزه

عرض:

1219 میلی متر

نوع برش:

برش هیدرولیکی

سیستم کنترل:

PLC

ضخامت:

0.8 - 1.5 میلی متر

سرعت:

8-10 متر / دقیقه

نکات کلیدی فروش:

طول عمر طولانی

برجسته کردن:

1.2mm floor deck roll forming machine,profile floor deck roll forming machine,pressing dot floor deck forming machine

profile floor deck roll forming machine

pressing dot floor deck forming machine

شرایط پرداخت و ارسال

مقدار حداقل تعداد سفارش

1 مجموعه

قیمت

negotiable

جزئیات بسته بندی

40 دقیقه FLC

زمان تحویل

30 روز کاری

شرایط پرداخت

L/C ، T/T ، D/A ، D/P

قابلیت ارائه

20 ست در ماه

محصولات مرتبط

ویدئو

Cellular Composite Roofing Sheet Making Machine 3.0" Width 0.8-2.0MM Thickness

بهترین قیمت رو بدست بیار

ویدئو

13 Rows Roof Tile Roll Forming Machine For Tipo Teja Americana Normal Tile

بهترین قیمت رو بدست بیار

ویدئو

Decking Flooring Board 1.2mm Floor Tile Making Machine

بهترین قیمت رو بدست بیار

ویدئو

45 Steel Deck Roll Forming Machine Cold ±2mm Cutting Tolerance Excellent Performance

بهترین قیمت رو بدست بیار

با ما تماس بگیرید

هم اکنون تماس بگیرید

توضیح محصول

USA Market Popular B Deck Profile Roll Forming Machine With Pressing Dot

Floor deck machine is a kind of building material that combines steel bars welded into trusses with galvanized steel sheets (floor slabs).
In the engineering project, the steel truss floor slab can play its unique role in different stages.
For example, when people work on the project, it can more support the building materials and construction pressure;
When used, it can also be combined with concrete to form a reinforced concrete truss with strong bearing capacity.

Specification

1	Control system	PLC brand :Delta / Panasonic
2	Cutting system	Hydraulic cutting by pillar type
3	Rows of rollers	26Rows
4	Total power	11+11+5.5KW
5	The thickness of raw material	0.67-1.2mm
6	Diameter OF shaft	￠90mm
7	Voltage	220V 60Hz 3phases

Guarantee

1. Guaranteed against malfunctions due to manufacturing defects for1 years after date of purchase except Electrical parts.

2. Repairs will not be performed even during the guarantee period in the follow circumstances

- Damage occurs due to a natural disaster

- Malfunction occurs due to user error

- Malfunction occurs due to modifications

- Malfunction occurs due to further movement or shipment after installation

Payment terms

40% in advance as down payment

60% is paid before the shipment is processed

Delivery

FOB: Tianjin Xingang Port

The Delivery Time: 30 days after the down payment is received.
