Slat Ppgi Shutter Door Roll Forming Machine Fully Automatic

shutter door roll forming machine ppgi,fullyautomatic shutter door roll forming machine,ppgl roller shutter door making machine

fullyautomatic shutter door roll forming machine

ppgl roller shutter door making machine

محل منبع:

سرزمین اصلی چین

نام تجاری:

FMS

گواهی:

ISO CE

با ما تماس بگیرید

درخواست قیمت

جزئیات محصول

نام محصول:

دستگاه شکل دهی درب کرکره ای تمام اتوماتیک

مواد خام:

PPGI، GI، PPGL GL

سرعت کار:

15-20 متر در دقیقه

ضخامت نورد:

0.3 میلی متر - 0.8 میلی متر

ابعاد (L*W*H):

4*1*1.4 متر

وضعیت:

جدید

ولتاژ:

380 ولت

ماده شفت:

فولاد شماره 45

برجسته کردن:

shutter door roll forming machine ppgi,fullyautomatic shutter door roll forming machine,ppgl roller shutter door making machine

fullyautomatic shutter door roll forming machine

ppgl roller shutter door making machine

شرایط پرداخت و ارسال

مقدار حداقل تعداد سفارش

1 مجموعه

قیمت

negotiable

جزئیات بسته بندی

20 دقیقه FLC

زمان تحویل

30 روز کاری

شرایط پرداخت

L/C ، T/T ، D/A ، D/P

قابلیت ارائه

20 ست در ماه

محصولات مرتبط

ویدئو

Metal Chain Driving Shutter Door Roll Forming Machine Speed 20-30m/Min

بهترین قیمت رو بدست بیار

ویدئو

Customized High Speed PU Door Roller Shutter Roll Forming Machine

بهترین قیمت رو بدست بیار

ویدئو

3T Shutter Door Roll Forming Machine For 0.8-1.2mm Thickness And 6.5m0.95m1.2m Size

بهترین قیمت رو بدست بیار

ویدئو

45 Steel Roller Material Shutter Door Roll Forming Machine with 7.5KW PLC Control System

بهترین قیمت رو بدست بیار

با ما تماس بگیرید

86-317-2016816

هم اکنون تماس بگیرید

توضیح محصول

Shutter Door Slat Forming Machine Fully Automatic

In order to keep the product shape and precision, adopts welded sheet structure, motor reducer drive, chain transmission, roller wa chromed which can keep the molding plate surface smooth and not easy to be marked when it is working

Feature: Ensure stability, precision and lifetime

Profile Drawing

Specification

main forming machine	Forming steps	14 steps
	Shaft diameter	40mm
	Machine stand	Memorial arch frame
	Machine frame	carbon steel welded
	Roller material	GCr12MoV
	Shaft material	45# steel
	Work speed	15-20m/min
	Transport	By gear
	Power of main machine	3kw
	Voltage	380V-50HZ-3P(as required)
	Machine dimension	411.4m
	Machine weight	about 2.2T
	Machine color	Yellow and blue(as required)

Slat Ppgi Shutter Door Roll Forming Machine Fully Automatic 1

Guarantee

1. Guaranteed against malfunctions due to manufacturing defects for1 years after date of purchase except Electrical parts.
2. Repairs will not be performed even during the guarantee period in the follow circumstances

- Malfunction occurs due to user error

- Malfunction occurs due to modifications

- Malfunction occurs due to further movement or shipment after installation

Payment terms

40% in advance as down payment
60% is paid before the shipment is processed

Delivery

FOB: Tianjin Xingang Port
The Delivery Time: 30 days after the down payment is received.
