Name: Plc Ppgi Roller Shutter Door Forming Machine 0.3-1.2mm
Brand: Cangzhou Famous International Trading Co., Ltd
SKU: نوار شاتر
Price: 12000.00 USD
Availability: InStock

خانه > محصولات > دستگاه رول فرمینگ درب کرکره ای >

Plc Ppgi Roller Shutter Door Forming Machine 0.3-1.2mm

ppgi roller shutter door forming machine,1.2mm roller shutter door forming machine,plc door shutter roll forming machine

1.2mm roller shutter door forming machine

plc door shutter roll forming machine

محل منبع:

سرزمین اصلی چین

نام تجاری:

CANGZHOU FMS

گواهی:

ISO CE

شماره مدل:

نوار شاتر

با ما تماس بگیرید

درخواست قیمت

جزئیات محصول

نام محصول:

شاتر درب بخش رول شکل دهی ماشین شاتر

مواد خام:

گالوالوم، گالوانیزه، PPGI

ظرفیت تولید:

8-15 متر در دقیقه

ولتاژ:

380V 50HZ 3Pa

وزن:

ضخامت:

0.3-1.2mm

ابعاد (L*W*H):

5000mm*1000mm*1500mm

مواد غلتک:

45 #فولاد با روکش کروم سخت

سیستم کنترل:

PLC (مارک وارداتی)

برجسته کردن:

ppgi roller shutter door forming machine,1.2mm roller shutter door forming machine,plc door shutter roll forming machine

1.2mm roller shutter door forming machine

plc door shutter roll forming machine

شرایط پرداخت و ارسال

مقدار حداقل تعداد سفارش

1 مجموعه

قیمت

negotiable

جزئیات بسته بندی

20 دقیقه FLC

زمان تحویل

30 روز کاری

شرایط پرداخت

L/C ، T/T ، D/A ، D/P

قابلیت ارائه

20 ست در ماه

محصولات مرتبط

ویدئو

Metal Chain Driving Shutter Door Roll Forming Machine Speed 20-30m/Min

بهترین قیمت رو بدست بیار

ویدئو

Customized High Speed PU Door Roller Shutter Roll Forming Machine

بهترین قیمت رو بدست بیار

ویدئو

3T Shutter Door Roll Forming Machine For 0.8-1.2mm Thickness And 6.5m0.95m1.2m Size

بهترین قیمت رو بدست بیار

ویدئو

45 Steel Roller Material Shutter Door Roll Forming Machine with 7.5KW PLC Control System

بهترین قیمت رو بدست بیار

با ما تماس بگیرید

هم اکنون تماس بگیرید

توضیح محصول

Shutter Door Section Roll Forming Machine Shutter Slat

Production Process:

Uncoiling→ Feeding material into machine →Roll forming → Auto cutting →Products receiving

Warranty

one year, and we will provide technical support for wholelife of the equipment.

If some parts of machine broken within 2 year, we will give customer the spare parts for free. (include chain, bearing, roller,oil pipe, counting wheel) If more than 2 year, maybe some spare parts need to be charged. If machine can not work well, we can teach them online until the machine is perfect. If you need, we can go to your place to assist you. But you need to provide the cost of the engineer.(plane ticket, food, hotel and per day 80$ salary)

Specification

Suitable Material	Material	GI, PPGI, PPGL
	Width	170 mm
	Thickness	0.3-1.2 mm
Material of rollers		High grade 45# forged steel, surface hard chromium plating
Rows of rollers		12 stations
Material of shafts		High grade 45# forged steel
Diameter of shafts		50 mm
Material of cutting blade		Cr12 Heat Treatment
Cutting Mode		Hydraulic Guide Column
Speed		15-20 m/min
Side plate thickness		16 mm
Chain size		1 inch
Total power		4 kw
Voltage		380V 50HZ 3Phase
Appearance size (About)		5000mm1000mm1500mm
Weight(About)		3 tons
Length measurement		Encoder
Control mode		Delta PLC
Operating mode		Button + Delta Touch screen

Guarantee

1. Guaranteed against malfunctions due to manufacturing defects for1 years after date of purchase except Electrical parts.

2. Repairs will not be performed even during the guarantee period in the follow circumstances

- Damage occurs due to a natural disaster

- Malfunction occurs due to user error

- Malfunction occurs due to modifications

- Malfunction occurs due to further movement or shipment after installation

Payment terms

40% in advance as down payment

60% is paid before the shipment is processed

Delivery

FOB: Tianjin Xingang Port

The Delivery Time: 30 days after the down payment is received.
