خانه > محصولات > دستگاه رول فرمینگ پانل دیواری >

3 Phase Ibr Steel Roof Sheet Making Machine Long Span

ibr steel roof sheet making machine,3phase steel roof sheet making machine,long span metal roofing roll former

3phase steel roof sheet making machine

long span metal roofing roll former

محل منبع:

چین

نام تجاری:

FMS

گواهی:

CE,ISO

با ما تماس بگیرید

درخواست قیمت

3 Phase Ibr Steel Roof Sheet Making Machine Long Span

جزئیات محصول

نام محصول:

Ibr فلزی پانل دیوار سقف کاشی سقف فولادی رول دستگاه شکل دهی بلند

مناسب برای پردازش:

صفحه فولادی

ضخامت سیم پیچ:

0.3-0.8mm

سیستم برش:

350 ساعت

وزن:

6.5T

ولتاژ:

380 ولت 3 فاز 50 هرتز

مواد برش:

فولاد قالب CR12 با عملیات خاموش شده

هیدرولیک:

40#

برجسته کردن:

ibr steel roof sheet making machine,3phase steel roof sheet making machine,long span metal roofing roll former

3phase steel roof sheet making machine

long span metal roofing roll former

شرایط پرداخت و ارسال

مقدار حداقل تعداد سفارش

1 مجموعه

قیمت

negotiable

جزئیات بسته بندی

دستگاه اصلی برهنه است، جعبه کنترل کامپیوتر توسط پلاستیک بسته بندی شده است.

زمان تحویل

30 روز

شرایط پرداخت

T/T ، Western Union

قابلیت ارائه

30 مجموعه در هر ماه

محصولات مرتبط

ویدئو

2025 New Design Metal Picket Fence Roll Forming Machine Fence Lines America Style

بهترین قیمت رو بدست بیار

ویدئو

Corrugated Container Board 15m/Min Wall Panel Roll Forming Machine Fully Automatic

بهترین قیمت رو بدست بیار

ویدئو

Trapezoid Steel Roof PPGL Wall Panel Roll Forming Machine 3phases

بهترین قیمت رو بدست بیار

ویدئو

Iron 0.8mm Corrugated Roofing Sheet Roll Forming Machine Hydraulic Cut

بهترین قیمت رو بدست بیار

با ما تماس بگیرید

هم اکنون تماس بگیرید

توضیح محصول

Ibr Metal Wall Panel Roof Tile Roof Steel Roll Forming Machine Long Span

IBR is widely used in the roofing industry and a common product used in roofing applications from industrial,commercial to residential applications.
It has become a household name in the South African building industry. The IBR's deep, broad flute design offers first-rate drainage abilities with ideal weight versus load/span characteristics. IBR can be factory Cranked, Curved and Bullnosed to various radii depending on customer's requirements.

Equipment Detailed Parameters:

No.	Ibr Metal Wall Panel Roof Tile Roof Steel Roll Forming Machine Long Span
1	Suitable material	Color steel sheet ,galvanized steel sheet, aluminium sheet
2	Width of material	1000mm or as customer's requirements
3	Thickness of material	0.3-0.8mm or as your needs
4	Working speed	0-15m/min
5	Electrical control system	PLC control system
6	Shaft diameter	80mm/85mm/90mm
7	Dimension	7500x1500x1920mm
8	Voltage	380V 3phase 50Hz or as the customer's requirements
9	Material of roller	High grade 45# forged steel plated with hard chrome plating
10	Material of cutting	Cr12 mould steel with quenched treatment
11	Working time	Can be 24 hours

Guarantee

1. Guaranteed against malfunctions due to manufacturing defects for1 years after date of purchase except Electrical parts.

2. Repairs will not be performed even during the guarantee period in the follow circumstances

- Damage occurs due to a natural disaster

- Malfunction occurs due to user error

- Malfunction occurs due to modifications

- Malfunction occurs due to further movement or shipment after installation

Payment terms

40% in advance as down payment

60% is paid before the shipment is processed

Delivery

FOB: Tianjin Xingang Port

The Delivery Time: 30 days after the down payment is received.
