Fast Speed Metal Door Frame Roll Forming Machine Customized

fast metal door frame roll forming machine,customized metal door frame roll forming machine,customized steel door roll forming machine

customized metal door frame roll forming machine

customized steel door roll forming machine

محل منبع:

سرزمین اصلی چین

نام تجاری:

FMS

گواهی:

ISO CE

با ما تماس بگیرید

درخواست قیمت

جزئیات محصول

نام محصول:

ماشین رول شکل دهی قاب فلزی با سرعت سریع کارخانه سفارشی شده است

ظرفیت تولید:

15-20 متر در دقیقه

ولتاژ:

380V/50HZ/60ph

اجزای اصلی:

موتور، گیربکس، PLC

ابعاد (L*W*H):

10.5*0.9*1.450 متر

سیستم کنترل:

PLC

ضخامت نورد:

1.2-1.5 میلی متر

ایجاد سرعت:

15 تا 20 دقیقه در متر

نوع برش:

برش هیدرولیک

برجسته کردن:

fast metal door frame roll forming machine,customized metal door frame roll forming machine,customized steel door roll forming machine

customized metal door frame roll forming machine

customized steel door roll forming machine

شرایط پرداخت و ارسال

مقدار حداقل تعداد سفارش

1 مجموعه

قیمت

negotiable

جزئیات بسته بندی

20 دقیقه FLC

زمان تحویل

30 روز کاری

شرایط پرداخت

L/C ، T/T ، D/A ، D/P

قابلیت ارائه

20 ست در ماه

محصولات مرتبط

ویدئو

Metal Chain Driving Shutter Door Roll Forming Machine Speed 20-30m/Min

بهترین قیمت رو بدست بیار

ویدئو

Customized High Speed PU Door Roller Shutter Roll Forming Machine

بهترین قیمت رو بدست بیار

ویدئو

3T Shutter Door Roll Forming Machine For 0.8-1.2mm Thickness And 6.5m0.95m1.2m Size

بهترین قیمت رو بدست بیار

ویدئو

45 Steel Roller Material Shutter Door Roll Forming Machine with 7.5KW PLC Control System

بهترین قیمت رو بدست بیار

با ما تماس بگیرید

86-317-2016816

هم اکنون تماس بگیرید

توضیح محصول

Fast Speed Metal Door Frame Roll Forming Machine Factory Customized

Doorframe And Fire Door Roll Forming Machine Doorframe Roll Forming Line.It can produce a structural doorframe, fire door and clean panel, doorframe roll forming line of KINDUS can automatically control according to the width of product.Widely used in various industrial, factory, villa building, civilian building, warehouse and have features such as nice appearance and durable.We can manufacture various kinds of machines to satisfy our customer, you can also provided the drawings what you want or the samples, we will design the project for you accordingly.

Specification

Technical Parameters (some depend on the final design)
1	Machine Type	Door frame
2	Machine Dimension (mm)	105009001450
3	Total Wight (Kg)	6000
4	Forming Steps	16
5	Forming Speed (m/min)	15-20m/min
6	Hydraulic Station Power(KW)	7.5
7	Diameter of Shaft (mm)	75
8	Electric Condition	380V/3Phase/ 50HZ
9	Power for Hydraulic Uncoiler(KW)	3KW
10	Recoiler Max Capacity (KGS)	5Tons
11	Control System	PLC
12	Raw Material Thickness (mm)	1.2-1.5mm
13	Effective Width(mm)	58mm
14	Material Width(mm)	500mm
15	Serial Number	BG2020006

Guarantee

1. Guaranteed against malfunctions due to manufacturing defects for1 years after date of purchase except Electrical parts.

2. Repairs will not be performed even during the guarantee period in the follow circumstances

- Damage occurs due to a natural disaster

- Malfunction occurs due to user error

- Malfunction occurs due to modifications

- Malfunction occurs due to further movement or shipment after installation

Payment terms

40% in advance as down payment

60% is paid before the shipment is processed

Delivery

FOB: Tianjin Xingang Port

The Delivery Time: 30 days after the down payment is received.
