Name: 100 MM Color Steel Round Downspout Roll Forming Machine Metal Automatic
Brand: Cangzhou Famous International Trading Co., Ltd
SKU: دستگاه رول شکل دهی لوله پایین
Price: 16,500.00 USD
Availability: InStock

خانه > محصولات > دستگاه رول شکل دهی لوله پایین >

100 MM Color Steel Round Downspout Roll Forming Machine Metal Automatic

100MM Downspout Roll Forming Machine,Round Downspout Roll Forming Machine,Automatic Downspout Roll Forming Machine

Round Downspout Roll Forming Machine

Automatic Downspout Roll Forming Machine

محل منبع:

چین

نام تجاری:

CANGZHOU FMS

گواهی:

ISO CE

شماره مدل:

دستگاه رول شکل دهی لوله پایین

با ما تماس بگیرید

درخواست قیمت

جزئیات محصول

نام محصول:

100 میلی متر فولاد رنگی گرد رول داون اسپوت دستگاه شکل دهی فلزی اتوماتیک

ظرفیت تولید:

13-15 متر در دقیقه

وزن:

6850 کیلوگرم

عرض تغذیه:

500 میلی متر

ابعاد (L*W*H):

7.5 * 1.65 * 1.5 متر

قدرت اصلی ماشین:

5.5 کیلووات

ولتاژ:

380 ولت 50 هرتز 3 فاز یا به عنوان الزامات

اتهام اتوماسیون:

تمام توان

ضخامت نورد:

0.4-0.8 میلی متر

برجسته کردن:

100MM Downspout Roll Forming Machine,Round Downspout Roll Forming Machine,Automatic Downspout Roll Forming Machine

Round Downspout Roll Forming Machine

Automatic Downspout Roll Forming Machine

شرایط پرداخت و ارسال

مقدار حداقل تعداد سفارش

1 مجموعه

قیمت

negotiable

جزئیات بسته بندی

20 دقیقه FLC

زمان تحویل

30 روز کاری

شرایط پرداخت

L/C ، T/T ، D/A ، D/P

قابلیت ارائه

20 ست در ماه

محصولات مرتبط

Mobile Vegetable Planting Trough Forming Machine with Hydraulic Motor 5.5KW and 8-15m/min Production Capacity for Greenhouse Vegetable Cultivation

بهترین قیمت رو بدست بیار

Portable Gutter Roll Forming Machine with 500mm Feeding Width and 8-15m/min Production Capacity for Various Growing Methods

بهترین قیمت رو بدست بیار

Mobile Greenhouse Vegetable Planting Trough Forming Machine With Quickly And Efficiently 5.5KW Hydraulic Motor

بهترین قیمت رو بدست بیار

Portable Greenhouse Planting Trough Forming Machine with Hydraulic Motor 5.5KW 380V/50Hz/3Phase and 45# Steel Shaft

بهترین قیمت رو بدست بیار

با ما تماس بگیرید

86-317-2016816

هم اکنون تماس بگیرید

توضیح محصول

100 MM Color Steel Round Downspout Roll Forming Machine Metal Automatic

100 MM Color Steel Round Downspout Roll Forming Machine Metal Automatic Work Flow
Decoiler→Manual Pre-Cutter→Guide Feeding →Roll Forming System→Hydraulic Post Cutter →Exit Rack

Downspout roll forming machine, known as rainwater downpipe roll forming machine as well, has been designed for making square or round (circle or rectangular) rainwater pipes. downspout has many different names as, waterspout, downpipe, drain spout, and roof drain pipe etc

Our downspout roll forming machine is special for manufacturing various size round downspout and rectangular downspout pipe.Downspout (Down pipe) is a pipe for conveying rain water from a roof or gutter to the ground or to a drain., also referred to as Leaderpipe, Downpipe, or Drainspout. The downspouts are more and more widely applied in rain water storage solution.

Specification

Tile Type	Colored Steel
Use	ROOF
Dimension(LWH)	7.51.651.5m
Weight	6850kg
Warranty	2 years
Key Selling Points	High Productivity
Rolling thinckness	0.4-0.8 mm
Warranty of core components	1.5 years
Core Components	Motor, Bearing, PLC
Product name	Downspout Roll Forming Machine
Color	Client's Request
Cutting blade material	Cr12 Quenched
Control system	Fully Automatic Computer Control

Installation

During the installation and adjustment of the equipment, our engineers shall provide the training to the buyer’s personal request to operate and maintain the equipment. Including foundation construction, electrical works, hydraulic oil, safe operation, and non-standard safety items, testing material and etc.

Guarantee

The warranty will be maintenance, maintain in the guarantee period of 18 months starting from delivery. Because of the quality of equipment during the guarantee period, we will provide the parts free of charge, which is in the conditions of correct operation. (Natural disasters or factors which can’t be forced by human are excluded).

Payment terms

40% in advance

60% is paid before shipping

100 MM Color Steel Round Downspout Roll Forming Machine Metal Automatic 0
