Product Description:
The Double Layer Roll Forming Machine is an advanced equipment for producing roofing tiles. It offers a perfect combination of speed, precision and efficiency. The machine is equipped with a 400mm wide roller and a hydraulic cutting system for precise and fast cutting. With its advanced PLC control system, users can customize the cutting length according to their requirements. This double layer roofing tile machine is particularly suitable for producing high-quality corrugated roofing tiles, and can also be used for producing roofing tiles with different widths and shapes. It runs on a 380V/50HZ/3Phase voltage, and is designed to meet the highest industry standards. It is an ideal choice for those who are looking for a reliable, efficient and cost-effective solution for their roofing tile production needs.
Features:
- Product Name: Double Layer Roll Forming Machine
- Cutting System: Hydraulic Cutting
- Roller Width: 400mm
- Machine Weight: 3.5T
- Power: 4KW
- Control System: PLC
- Specialty: Trapezoid and Corrugated Roofing Tile, Double Layer Roof Sheet Machine
Technical Parameters:
| Product Name |
Parameters |
| Double Layer Roll Forming Machine |
Roller Diameter: 70mm
Cutting System: Hydraulic Cutting
Control System: PLC
Forming Width: 1000mm
Machine Size: 7.5m*1.2m*1.5m
Cutting Length: Any Length
Power: 4KW
Roller Material: 45# Steel
Forming Speed: 10-15m/min |
| IBR and Corrugated Roof Sheet Machine |
Roller Diameter: 70mm
Cutting System: Hydraulic Cutting
Control System: PLC
Forming Width: 1000mm
Machine Size: 7.5m*1.2m*1.5m
Cutting Length: Any Length
Power: 4KW
Roller Material: 45# Steel
Forming Speed: 10-15m/min |
| Double Layer Roofing Tile Machine |
Roller Diameter: 70mm
Cutting System: Hydraulic Cutting
Control System: PLC
Forming Width: 1000mm
Machine Size: 7.5m*1.2m*1.5m
Cutting Length: Any Length
Power: 4KW
Roller Material: 45# Steel
Forming Speed: 10-15m/min |
| Trapezoid and Corrugated Roofing Tile Making Machine |
Roller Diameter: 70mm
Cutting System: Hydraulic Cutting
Control System: PLC
Forming Width: 1000mm
Machine Size: 7.5m*1.2m*1.5m
Cutting Length: Any Length
Power: 4KW
Roller Material: 45# Steel
Forming Speed: 10-15m/min |
Applications:
The FMS Double Layer Roll Forming Machine is a kind of corrugated roofing tile machine used for double layer roof sheet production. This machine is certified with CE, and with a minimum order quantity of 1. You can purchase the machine with a price of 15000 USD, and the package is usually naked with plastic film. It usually takes 40 days for delivery. The payment terms are T/T, L/C. FMS can supply 50 sets of the machine every month. With the forming width of 1000mm, the machine size is 7.5m*1.2m*1.5m. The cutting system is hydraulic cutting, and the roller diameter is 70mm.
The FMS Double Layer Roll Forming Machine is widely used for double layer roof sheet production. It is often used in the production of construction materials, such as double layer roof sheets, corrugated roofing tiles, and other industrial products. The double layer roof sheet machine is a high-quality product with advanced technology. It has high efficiency, stability, and accuracy in production. It is an ideal choice for all kinds of roof sheet production.
Customization:
FMS Double Layer Roll Forming Machine
Brand Name: FMS
Model Number: FMS-double layer
Place of Origin: China
Certification: CE
Minimum Order Quantity: 1
Price: 15000
Packaging Details: NAKED with plastic film
Delivery Time: 40 dyas
Payment Terms: T/T,L/C
Supply Ability: 50 SETS
Roller Stations: 18-20
Machine Weight: 3.5T
Voltage: 380V/50HZ/3Phase
Roller Width: 400mm
Forming Width: 1000mm
FMS Double Layer Roll Forming Machine is designed to produce IBR and corrugated roof sheet machine, trapezoid roof sheet machine, trapezoid and corrugated roofing tile machine. It has a roller station of 18-20 and machine weight of 3.5T. The voltage is 380V/50HZ/3Phase. The roller width is 400mm and forming width is 1000mm.
Support and Services:
Technical Support and Service for Double Layer Roll Forming Machine
At XYZ, we provide a wide range of technical support and services for our Double Layer Roll Forming Machine. Our experienced technicians can help you troubleshoot any issues you encounter with your machine, as well as provide maintenance advice and support.
We have a dedicated technical support team that is available 24/7 to provide assistance. We also provide online resources such as manuals, FAQs, and instructional videos to help you get the most out of your machine.
Our team of experienced technicians also offers on-site repair and maintenance services. We have a variety of spare parts and components available, so you can rest assured that any repairs will be completed quickly and efficiently.
At XYZ, we pride ourselves on providing the best support and services for our Double Layer Roll Forming Machines. If you ever have any questions or concerns, don’t hesitate to contact us.
Packing and Shipping:
The Double Layer Roll Forming Machine will be packaged and shipped in a strong wooden box, with the necessary foam or other cushioning materials used to protect the Machine from any external impacts during transportation. The box and its contents will be clearly labeled with a shipping address, item name, and model to ensure that it is delivered to the correct address.
