Name: 0.8mm Ppgi Cold Roll Forming Machine Metal Frame U Channel Purlin Making
Brand: Cangzhou Famous International Trading Co., Ltd
SKU: کانال درب کرکره ای
Price: 12000.00 USD
Availability: InStock

خانه > محصولات > دستگاه رول فرمینگ درب کرکره ای >

0.8mm Ppgi Cold Roll Forming Machine Metal Frame U Channel Purlin Making

cold roll forming machine ppgi,purlin roll forming machine ppgi,0.8mm cold roll forming machine

purlin roll forming machine ppgi

0.8mm cold roll forming machine

محل منبع:

سرزمین اصلی چین

نام تجاری:

CANGZHOU FMS

گواهی:

ISO CE

شماره مدل:

کانال درب کرکره ای

با ما تماس بگیرید

درخواست قیمت

جزئیات محصول

نام محصول:

پانل درب ساخت ماشین آلات کرکره نورد غلتکی ماشین

سرعت:

15 متر در دقیقه

ولتاژ:

380 ولت 50 هرتز 3 فاز یا سفارشی سازی

مواد برش:

45# فولاد آهنگری آبکاری شده با کروم سخت

اجزای اصلی:

موتور، بلبرینگ، دنده، پمپ، PLC

قدرت:

3kw/5.5kw

سیستم کنترل:

PLC

وزن:

1500 کیلوگرم

برجسته کردن:

cold roll forming machine ppgi,purlin roll forming machine ppgi,0.8mm cold roll forming machine

purlin roll forming machine ppgi

0.8mm cold roll forming machine

شرایط پرداخت و ارسال

مقدار حداقل تعداد سفارش

1 مجموعه

قیمت

negotiable

جزئیات بسته بندی

20 دقیقه FLC

زمان تحویل

30 روز کاری

شرایط پرداخت

L/C ، T/T ، D/A ، D/P

قابلیت ارائه

20 ست در ماه

محصولات مرتبط

ویدئو

Metal Chain Driving Shutter Door Roll Forming Machine Speed 20-30m/Min

بهترین قیمت رو بدست بیار

ویدئو

Customized High Speed PU Door Roller Shutter Roll Forming Machine

بهترین قیمت رو بدست بیار

ویدئو

3T Shutter Door Roll Forming Machine For 0.8-1.2mm Thickness And 6.5m0.95m1.2m Size

بهترین قیمت رو بدست بیار

ویدئو

45 Steel Roller Material Shutter Door Roll Forming Machine with 7.5KW PLC Control System

بهترین قیمت رو بدست بیار

با ما تماس بگیرید

هم اکنون تماس بگیرید

توضیح محصول

Metal Frame C Purlin Channel Cold Rolling Making Machine

Roller shutter door channel roll forming machine is used for producing shutter door side channel ,which will be used together with guide rail and bottom rail .the Raw material for shutter door machine is galvanized coil or pre painted steel coil ,coil thickness is 0.8-1.2mm ,for this type machine have been sent to many countries such as Singapore,Oman ,Pakistan ,Dominica etc
Slat shutter door U channel machine is the most common style ,it is used fro making flat shutter door panels ,simple but strong and cost effective ,many custoners choose this style

Specification

No	Item	Specification
Material	Raw material	GI or PPGI
	Material thickness	0.8-1.2MM
Machine body	Roller material	Cr12 quenched
	Shaft material	High grade 45# steel with Cr12 quenched
	Shaft diameter	50mm
	Roller stations	15
	Middle plate thickness	16mm
	Machine size	50.81.2m
	Productivity	8-15m/min
Cutter	Material	GCR12
	Method	Hydraulic cutting
Power	Driving way	Chain 1.2 inch
	Motor	4KW
	Hydraulic oil pump	3KW
	Voltage	380V,50HZ ,3 phase or customized as your need

0.8mm Ppgi Cold Roll Forming Machine Metal Frame U Channel Purlin Making 0

Guarantee

In correct operation and maintenance, the machines are 12 months quality guarantee from time of loading, life guarantee repair; within quality guarantee period, except for failures caused by human error, spare parts will be provided freely; after the quality guarantee period, only charge the cost of the spare parts. Free technical supporting and maintenance consulting in lifetime.

Payment terms

35 % in advance as down payment
65 % is paid before the shipment is processed

Delivery

FOB: Tianjin Xingang Port
The Delivery Time: 30 days after the down payment is received.
