Name: Sandwich Roof Wall Panel Making Machine EPS Panel Press Machine Product Line Forming Speed 3-6m/Min
Brand: Cangzhou Famous International Trading Co., Ltd
SKU: FMS-ساندویچ
Price: 57,500.00 USD
Availability: InStock

خانه > محصولات > دستگاه ساندویچ پانل رول فرمینگ >

Sandwich Roof Wall Panel Making Machine EPS Panel Press Machine Product Line Forming Speed 3-6m/Min

Sandwich Roof Wall Panel Making Machine,EPS Panel Press Machine,EPS Panel Press Product Line

EPS Panel Press Machine

EPS Panel Press Product Line

محل منبع:

چین

نام تجاری:

FMS

گواهی:

شماره مدل:

FMS-ساندویچ

با ما تماس بگیرید

درخواست قیمت

جزئیات محصول

سیستم برش:

برش ردیابی پرواز

قدرت حرکتی اصلی:

مجموع 32 کیلو وات

درمان سطح غلتکی:

پولیش و آبکاری کروم

خطای برش طول:

± 2 میلی متر

ولتاژ:

380V/50Hz/3Phase

بعد:

45 متر * 2.5 متر * 2.4 متر

گارانتی:

2 سال

نام محصول:

دستگاه ساخت پنل ساندویچ

برجسته کردن:

Sandwich Roof Wall Panel Making Machine,EPS Panel Press Machine,EPS Panel Press Product Line

EPS Panel Press Machine

EPS Panel Press Product Line

شرایط پرداخت و ارسال

مقدار حداقل تعداد سفارش

قیمت

40000-75000 usd

جزئیات بسته بندی

برهنه

زمان تحویل

45 روز

شرایط پرداخت

L/C، T/T

قابلیت ارائه

1000

محصولات مرتبط

Mode EPS Sandwich Panel Line for 50-300 Thickness Production Customization

بهترین قیمت رو بدست بیار

Eps Rock And Wool Sandwich Panel Production Machine For Customer Requirements

بهترین قیمت رو بدست بیار

32KW Hydraulic Motor Power Sandwich Panel Roll Forming Machine with Thickness 50-300mm

بهترین قیمت رو بدست بیار

High Efficiency Sandwich Panel Roll Forming Machine with Thickness 30-300mm

بهترین قیمت رو بدست بیار

با ما تماس بگیرید

86-317-2016816

هم اکنون تماس بگیرید

توضیح محصول

Product Description:

Rock Wool/mineral Wool Insulation Sandwich Panel Roll Forming Machine/production Line Prices

which have the best function of heat preservation, heat insulation, sound insulation, fire retardant, water proof, portable,
environmental protection etc. It can be widely used in the external wall of retaining and decoration of high-rise building and senior office building The Rock wool and foam sandwich panel is the new wall building material for retaining, decoration and heat preservation. It is the most popular of new generation of decorative wall retaining timber construction. The product of this line—Rock wool and foam sandwich panel is produced with foaming at working site. There’s device which can inject the foaming material between the upper and lower metal sheet ,then will be sent into double belt and evenly forwarded. The chemosynthesis and solidification are finished inside of double belt. The cutting is finished according to the length which is set before running themachine, it is non-stop cutting type, and the cutter will be moved along with the panel.

Technical Parameters:

1. Technique parameters of the processing line
(1) Coil material:	EPS, rock wool, glass silk floss and so on
(2) Thickness of the plate:	0.3-0.8mm
(3) Core thickness:	20-300mm
(4) Production capacity (according to yourglue):	4-4.5m/min (the fastest), 2-2.5m/min(the slowest)
(5) Total power:	about 30KW
(6) Weight:	25ton
(7) PLC control systerm, easy to operate, high precision and work stably.
(8) Dimensions of whole production line:	About Length35000mm × Width2500mm × Height2600mm

Packing and Shipping:

Product Packaging:

The sandwich panel roll forming machine will be packed in a strong wooden case.
All the parts and accessories will be securely wrapped and placed in the case.
The case will be clearly labeled with the product name and specifications.

Shipping:

The sandwich panel roll forming machine will be shipped by sea, air or land transport, depending on the customer's preference.
The shipping cost will be calculated based on the destination and the weight of the machine.
The machine will be shipped within 30 days after receiving the full payment.

FAQ:

Q: Are you a factory or a trading company?

We are a traditional factory transformed to foreign trade, so you can get the most favorable machine prices

Q:What's your Warranty ?

12 months, during which all parts damaged because of quality problem will be changed for free.

Q: What's your delivery Time ? Within 35-50 days after receiving prepaid. Some machines in stock, can be delivered at any time. Q: What's your payment terms ? 30% deposit is paid before production, the balance paid after inspection confirmation before shipment.

Q:What's your Install and Training ? If buyers come to our factory to inspect, the training to install and operate is provided
face to face. If not, manual and video is provided to show how to install and operate.

Q: What's you after-sale service ? We provide 24-hour online service for our customers. A.The seller will debug the machines freely in China, and the traffic expense in China of the technique people will be paid by the seller. When technique men go to the buyer's place to debug the machines, the buyer should pay the expense of accommodation, and traffic for the buyer’s men. B. If the buyer sends people to receive the training of the operation given by the seller, during the training period, the seller should pay the expense of accommodation, and traffic for the buyer's men.

Q: How to place order ? Inquiry---confirm the profile drawings and price----confirm the PI---arrange the deposit or L/C---then OK
