Name: Steel Metal Heavy Thickness Coil Leveling 1.5mm 1200mm PPGI Cut To Length
Brand: Cangzhou Famous International Trading Co., Ltd
SKU: به طول برش دهید
Price: 26,500.00 USD
Availability: InStock

خانه > محصولات > برش به طول و خط برش >

Steel Metal Heavy Thickness Coil Leveling 1.5mm 1200mm PPGI Cut To Length

steel metal coil leveling machine,heavy thickness PPGI cut to length,1200mm width coil leveling line

heavy thickness PPGI cut to length

1200mm width coil leveling line

محل منبع:

چین

نام تجاری:

CANGZHOU FMS

گواهی:

ISO, CE

شماره مدل:

به طول برش دهید

با ما تماس بگیرید

درخواست قیمت

Steel Metal Heavy Thickness Coil Leveling 1.5mm 1200mm PPGI Cut To Length

جزئیات محصول

نام محصول:

سیم پیچ فولادی ضخامت سنگین 1.5 میلی متر 1200 میلی متر PPGI برش به طول

مواد برش:

cr12mov

ضخامت مواد:

0.8mm -1.5mm

سرعت کار:

8 متر در دقیقه - 20 متر در دقیقه

وزن سیم پیچ:

5 تن / 7 تن / 10 تن / 15 تن

وزن ماشین:

13000 کیلوگرم

تحمل:

± 2 میلی متر

برجسته کردن:

steel metal coil leveling machine,heavy thickness PPGI cut to length,1200mm width coil leveling line

heavy thickness PPGI cut to length

1200mm width coil leveling line

شرایط پرداخت و ارسال

مقدار حداقل تعداد سفارش

1 مجموعه خط تولید

قیمت

negotiable

جزئیات بسته بندی

2 عدد 40 اینچ FLC

زمان تحویل

60 روز کاری

شرایط پرداخت

L/C ، D/A ، D/P ، T/T

قابلیت ارائه

5 ست در 60 روز

محصولات مرتبط

ویدئو

2025 Factory Price 40m/min High Speed Slitter Slitting Line Machine With Hydraulic Uncoiler And Recoiler

بهترین قیمت رو بدست بیار

ویدئو

2025 New Price 40m/min High Speed Slitter Slitting Line Machine With Hydraulic Uncoiler And Recoiler

بهترین قیمت رو بدست بیار

Steel Metal Heavy Thickness Coil Leveling 1.5mm 1200mm PPGI Cut To Length

بهترین قیمت رو بدست بیار

ویدئو

steel coile 40m/min High Speed Slitting Line Machine With Hydraulic Uncoiler And Recoiler

بهترین قیمت رو بدست بیار

با ما تماس بگیرید

هم اکنون تماس بگیرید

توضیح محصول

Steel Metal Heavy Thickness Coil Leveling 1.5mm 1200mm PPGI Cut To Length

Product Description

Multi-Function Metal Coil Leveling Slitting And Cut To Length

Steel Coil Cutting-to-Length Lines are integrated systems of machinery designed to process large, master coils of steel into flat sheets. This process is fundamental in metal manufacturing, transforming coiled raw material into ready-to-use flat products for various industries.

These highly automated lines handle the three primary functions: uncoiling, levelling (straightening), and cutting.

Specifications

No.	Item	Description
Main Specification
1	Raw Material	Galvanized, Aluminum, Color steel, Hardness 235MPa - 485MPa
2	Raw Material Thickness	0.2 mm - 3.0 mm
3	Raw Material Width	600 mm - 1600 mm
4	Tape Inner Diameter	φ 480 mm - φ 530 mm
5	Tape Outer Diameter	φ 1600 mm
6	Coil Weight	5 tons - 10 tons
7	Brand	FMS
8	The Highest Slitting Line Speed	8 m/min - 30 m/min
9	Minimum Cutting Line Width	35 mm
10	Cutting Width Precision	± 0.01 - ± 0.05 mm
11	Rated Operational Voltage	380 V, 3 Phase, 60 Hz
12	Total Weight	14000 KG
13	Working Space (L*W)	20000 mm * 6000 mm
Decoiler Machine Specification
1	Tape Outer Diameter	Max φ 1600 mm
2	Tape Width	600 mm - 1600 mm
3	Tape Inner Diameter	φ 480 mm - φ 530 mm
4	Coil Weight	5 /7/10 tons
5	Max Working Speed	8 m/min - 30 m/min
6	Tape Tight Range	φ 480 mm - φ 530 mm
7	Shaft Diameter	φ180 mm
8	Roller Effective Length	1600 mm
9	Drive Motor Power	5 KW
10	Loading Car Diameter	φ 700 mm - φ 1500 mm
11	Loading Car Weight	5 /7/ 10 tons
12	Car Speed	About 4 m/min

Application

Used to cut the big coils into different width coils. The thickness can be 0.3-3mm GI PPGI, with a working speed that can reach 40 meters per minute. Maximum width of steel coils can be 1250mm.

Advantage

Cangzhou Famous Cold Roll Forming Machinery is a professional manufacturer and exporter that specializes in the design, development and production of cold roll forming machines.

Located in Botou City, all products comply with international quality standards and are greatly appreciated in various markets throughout the world, including Asia, Africa, Europe, South America, and Australia.
